LEDstrip 24V Line IP20
- For a homogenous light – even without cover
- Fits excellent for all our aluminium profiles
- Comes with self-adhesive tape and 2m connecting cable (5m)
- Maximum length 5m, 512LED/m
- Upon request, running meters with connection cables are delivered according to your specifications; running meters are delivered as standard without connection cables
LEDstrip with technology that conceals the LED Chip and electronics under an homogenous phosphorous/silicone layer. Short spacing between the LEDs creates an even illuminated line without profile or cover. COB technology with high lumen output and very good efficiency. Cutting increments of 31,25 mm and seamless joints make it simple to adapt lengths. Comes as standard in rolls of five metres with 2 m connecting cable at each end, 1pc quick connection and self-adhesive tape for easy installation. Upon request, running meters with connection cables are delivered according to your specifications; running meters are delivered as standard without connection cables. Drivers are ordered separately according to required dimmer technology and placing. Maximum length 5m.
| Variants | GTIN | Item Name | Colour Temperature (K) | Luminaire Lumen (lm) |
|---|---|---|---|---|
|
7392971139197 | LEDstrip 24V Line IP20 MidLum 2700K lpm | 2700 | 900 |
|
7392971139180 | LEDstrip 24V Line IP20 MidLum 2700K 5m | 2700 | 4500 |
|
7392971139203 | LEDstrip 24V Line IP20 MidLum 3000K 5m | 3000 | 4750 |
|
7392971139210 | LEDstrip 24V Line IP20 MidLum 3000K lpm | 3000 | 950 |
|
|
7392971139227 | LEDstrip 24V Line IP20 MidLum 4000K 5m | 4000 | 5250 |
|
7392971139234 | LEDstrip 24V Line IP20 MidLum 4000K lpm | 4000 | 1050 |
LEDstrip 24V Line IP20 MidLum 2700K lpm
-
GTIN 7392971139197Item Name LEDstrip 24V Line IP20 MidLum 2700K lpmWarranty 5 years
- Light Technical Data
-
Luminaire Lumen (lm) 900Light Source LEDLight Source Included YesReplaceability Non-replaceaable LEDLED Colour Warm WhiteColour Temperature (K) 2700Colour Rendering Index (Ra) >90Colour Consistency (SDCM) 3Luminous Intensity (cd) 240Beam Angle (°) 150Light sharing SymmetricLight Outlet DirectNumber of Lamps (pcs) 1Number of LED (pcs) 512LED Pitch (mm) 2Life Time L70 50 000h Ta 25°CNominel Life Time (h) 50000Lumen maintenance 50 000h L70LLMF @ 50 000h 0,71
- Technical data
-
Voltage (type) DCVoltage Interval (V) 24...24Voltage Nominal (V) 24Voltage Forward (Vf) 3,2Power Luminaire (W) 10System Power (W) 11Efficiency Luminaire (lm/W) 90Efficiency System (lm/W) 82Energy Efficiency Class (EU) 2019/2015 F
- Operation and Connection
-
Dimmable YesDriver Included NoDriver Model Constant VoltageOperating TemperatureMax. Tc (°C) 65
- Color and material
-
Material CopperColor WhiteEnvironmental Assessment Byggvarubedömningen
- Measurement and installation
-
Operating EnvironmentIP Degree of Protection 20Protection Class IIIInstallation Surface mountedMounting Installation Self Adhesive TapeApproval Marks CEFilament Test IEC 695-2-1(°C) 650Requires cooling NoLength (mm) 1000Width (mm) 8Height (mm) 2Weight (kg) 0,02
- LEDstrips
-
Min. Bend Radius (mm) 10Min. Length (m) 0,031Max. Length (m) 5Cutting Increments (mm) 31,25
