LEDstrip RX HDI IP20

High lumen output and very good colour rendering, Ra > 90. Short spacing between LEDs, for homogenous light also in lower profiles
Comes with self-adhesive tape and quick connections (5m)
Should be installed in aluminium profiles for extra cooling
Maximum length 5m, 140LED/m
Upon request, running meters with connection cables are delivered according to your specifications; running meters are delivered as standard without connection cables

LEDstrip with short spacing between LEDs giving high lumen output with very good light quality and colour rendering, Ra>90. Perfect for a homogenous light with opal cover- also with lower profiles. Comes as standard in rolls of five metres with 2 m connecting cable at each end, 1pc quick connection and self-adhesive tape for easy installation. Also available made to measure in optional lengths with 5cm cut-off intervals. Upon request, running meters with connection cables are delivered according to your specifications; running meters are delivered as standard without connection cables. Drivers are ordered separately according to required dimmer technology and placing.

GTIN	Item Name	Colour Temperature (K)	Luminaire Lumen (lm)
7392971134666	LEDstrip RX HDI IP20 24V 3000K lpm	3000	1800
7392971134659	LEDstrip RX HDI IP20 24V 3000K 5m	3000	9000
7392971137568	LEDstrip RX HDI IP20 24V 4000K 5m	4000	10000
7392971137575	LEDstrip RX HDI IP20 24V 4000K lpm	4000	2000

Description: GTIN 7392971134666

Item Name LEDstrip RX HDI IP20 24V 3000K lpm

Warranty 5 years
Light Technical Data: Luminaire Lumen (lm) 1800

Light Source LED

Light Source Included Yes

Replaceability Non-replaceaable LED

LED Colour Warm White

Colour Temperature (K) 3000

Colour Rendering Index (Ra) >90

Colour Consistency (SDCM) 3

Luminous Intensity (cd) 575

Beam Angle (°) 120

Light sharing Symmetric

Light Outlet Direct

Number of Lamps (pcs) 1

Number of LED (pcs) 140

LED Pitch (mm) 7

Life Time L70 50 000h Ta 25°C

Nominel Life Time (h) 50000
Technical data: Adjustable No

Voltage (type) DC

Voltage Interval (V) 24...24

Voltage Nominal (V) 24

Voltage Forward (Vf) 3

Power Luminaire (W) 19,2

System Power (W) 21,12

Efficiency Luminaire (lm/W) 94

Efficiency System (lm/W) 85

Energy Efficiency Class (EU) 2019/2015 F
Operation and Connection: Dimmable Yes

Driver Included No

Driver Model Constant Voltage

Operating Temperature -20…+45

Max. Tc (°C) 75
Color and material: Material Copper

Color White

Environmental Assessment SundaHus, Byggvarubedömningen
Measurement and installation: Operating Environment Indoor / dry locations

IP Degree of Protection 20

Protection Class III

Installation Surface mounted

Mounting Installation Self Adhesive Tape

Approval Marks CE

Requires cooling Yes

Length (mm) 1000

Width (mm) 8

Height (mm) 2

Weight (kg) 0,15
LEDstrips: Min. Bend Radius (mm) 60

Min. Length (m) 0,05

Max. Length (m) 5

Cutting Increments (mm) 50
